Outdoor Exhibition Pagoda Tent

Outdoor Events Pagoda Tent Product Description
Outdoor events pagoda tents are tents with a high peak roof and aluminium square frame. The high peak height providing ample vertical space, This special shape makes event pagoda tent very attractive and easy to recognize. Outdoor events pagoda tents are often used as outdoor party tent, pagoda exhibition tent, and temporary industrial warehouse tent. Many event companies prefer outdoor events pagoda tents because they can be connected together to create a larger event space.

Outdoor Events Pagoda Tent The pagoda-style or conical roof design is not only aesthetically pleasing but also facilitates efficient water drainage, hence its designation as a waterproof pagoda tent. Constructed from high-strength PVC tarpaulin, it offers wind resistance, UV protection, and snow load capacity. The aluminium alloy frame is lightweight, durable, and reusable, adapting to diverse venues while delivering cost-effective solutions.

Specifications

Type	Width(m)	Bay distance (m)	Eave height (m)	Ridge height (m)	Main frame profile (mm)
JMT-3	3	3	2.3	3.9	48x84x3
JMT-4	4	4	2.3	4.5	48x84x3
JMT-5	5	5	2.5	5.1	48x100x3
JMT-6	6	6	2.5	5.6	68x122x3
JMT-8	8	4	2.5	6.1	68x122x3
JMT-10	10	5	2.5	6.6	68x122x3

The size can be customized as your wish, for example, 12x12m, 3m eave height.

Competitive Advantage:

Modular type, the tent can be extended or dismantled to several small tents.
Easy to be assembled and dismantled.
No pole inside, 100% space available.
The aluminum frame will never get rusty with life span more than 15 years.
The PVC cover is waterpprof, fireproof with life span 6-8 years.
Can be used in bad circumstance.

Key Characters

Frame part	Main parts: Aluminum alloy \| Spare parts: Durable galvanized steel. All aluminum components are technically anodized and all steel parts are well hot-dip galvanized.

Cover part	The roof and sidewall cover: double coated PVC fabric. The weight of fabric is from 650g/sqm to 850g/sqm.

Side wall	Performance: Waterproof, UV resistant, flame retardant to DIN4102, M2 and Grade B1, tear resistant, self-cleaning ability, etc. Material options: PVC wall, glass wall, sandwich panels, ABS panels, etc.

Fabric color option	White, transparent, green, yellow, red, blue, gray, black and customized
Applications	Wedding, events, temporary warehouse & workshop, exhibitions, church and other outdoor activities

Ground Situations	Grassland, sandy land, cement ground, marble ground, etc.
Fixing Solutions	Expansion screw, steel nail, weight plate, semi-permanent fixing, etc.
